GPU | AMD Radeon™ RX 9070 XT Graphics Card AMD RDNA™ 4 Architecture |
Engine Clock | Boost Clock: Up to 3010 MHz |
Game Clock: Up to 2460 MHz |
Stream Processors | 4096 |
Compute Units | 64 CUs (3rd Gen RT + 2nd Gen AI Accelerators) |
Infinity Cache | 64MB |
Ray Accelerators | 64 |
AI Accelerator | 128 |
Memory Size/Bus | 16GB/256 bit GDDR6 |
Memory Clock | 20 Gbps Effective |
Displays | Maximum 4 Displays |
Resolution | HDMI®: 7680×4320 |
DisplayPort™ 2.1a: 7680×4320 |
Interface | PCI-Express 5.0 x16 |
Output | 2x HDMI® |
| 2x DisplayPort™ 2.1a |
BIOS Support | UEFI |
Game Index | 4K |
Sapphire Features | Honeywell PTM7950 Thermal Interface Material (TIM) |
AeroCurve Fan Blade |
Free Flow |
FrameDefense |
Integrated Cooling Module |
Tri-X Cooling Technology |
High TG Copper PCB |
Optimized Composite Heatpipes |
Metal Backplate |
ARGB SAPPHIRE Logo |
Two-Ball Bearing Fans |
14-Phase Digital Power Design |
Fuse Protection |
Intelligent Fan Control |
Precision Fan Control |
TriXX Supported |
Performance vs. Efficiency Quicksets |
Glow! |
TriXX Boost |
External RGB LED MB Synchronization |
Accessories Bundled | L-Shape Support Bracket |
3pin 5V ARGB Cable |
AMD Features | AMD RDNA™ 4 Architecture |
64 Compute Units (3rd Gen RT + 2nd Gen AI Accelerators) |
AMD HYPR-RX with AFMF 2 |
AMD FidelityFX™ Super Resolution 4 with AI Upscaling |
DisplayPort™ 2.1a |
AMD Radiance Display™ Engine |
AMD Fluid Motion Frames 2 technology |
AMD Radeon™ Anti-Lag 2 technology |
AV1 Encode/Decode |
AMD FidelityFX™ technologies |
Microsoft® DirectX® 12 Ultimate |
AMD Noise Suppression |
AMD Freesync™ technology |
16 GB of GDDR6 on 256-bit Memory Bus |
AMD smart technologies |
AMD Software: Adrenalin Edition™ application |
Cooler Type | Tri-X Cooling |
AeroCurve Fan Blade |
Free Flow |
Integrated Cooling Module |
High TG Copper PCB |
Optimized Composite Heatpipes |
Two-Ball Bearing |
Form Factor | 3 slot, ATX |
Dimension: 320(L)X 120.25(W)X 61.6 (H)mm |
Power Consumption | 317W Typical Board Power |
OS | Linux®, Windows® 10, and Windows 11. 64-bit operating system required |
System Requirement | Minimum 750 Watt Power Supply |
2 x 8-pin Power Connector. |
PCI Express® based PC is required with one X16 lane graphics slot available on the motherboard. |
Minimum 8GB of system memory. 16GB recommended. |
