CPU | Support Intel® Core™ Ultra Processors |
Chipset | Intel® Z890 Chipset |
Bộ nhớ | 2 x DIMM slots, max. 96GB, DDR5 |
Support up to 8800+MT/s (OC), Non-ECC, |
Đồ họa | 1 x HDMI™ port** |
2 x Intel® Thunderbolt™ 4 ports (USB |
Type-C®) support DisplayPort and Thunderbolt™ video outputs*** |
* Graphics specifications may vary between |
CPU types. Please refer to www.intel.com for any updates. |
** Supports 4K@60Hz as specified in HDMI |
2.1. |
*** In Thunderbolt™ 4 mode, supports up to |
8K@60Hz x1 with DSC or 4K@60Hz x 2, maximum total bandwidth up to 23.8Gbps or |
16Gbps/16Gbps, for resolution support please check DisplayPort 2.1 specs. In DP |
alt mode, Only one USB Type-C® port supports up to UHBR20 at a time. |
Khe cắm mở rộng | Intel® Core™ Ultra Processors(Series 2)* |
1 x PCIe 5.0 x16 slot (supports x16 mode) |
* Please check the PCIe bifurcation table |
Lưu trữ | Total Supports 2 x M.2 slots and 2 x SATA |
6Gb/s ports* |
Intel® Core™ Ultra Processors(Series 2)** |
M.2_1 slot (Key M), type |
2230/2242/2260/2280 (supports PCIe 5.0 x4 mode) |
M.2_2 slot (Key M), type |
2230/2242/2260/2280 (supports PCIe 5.0 x4 mode) |
2 x SATA 6Gb/s ports*** |
* Intel® Rapid Storage Technology supports |
PCIe RAID 0/1, SATA RAID 0/1. |
** M.2_2 slot shares bandwidth with |
PCIEX16(G5). When M.2_2 slot is occupied with SSD device, PCIEX16(G5) will run |
x8 only. |
*** Install ROG FPS Card to support 2 x |
SATA 6Gb/s ports. |
Ethernet | 1 x Intel® 2.5Gb Ethernet |
ASUS LANGuard |
Không dây & Bluetooth | Wi-Fi 7* |
2x2 Wi-Fi 7 (802.11be) |
Supports 2.4/5/6GHz frequency band** |
Supports Wi-Fi 7 320MHz bandwidth, up to |
5.8Gbps transfer rate. |
Bluetooth® v5.4*** |
USB | Rear USB (Total 9 ports) |
2 x Thunderbolt™ 4 (2 x USB Type-C®) |
1 x USB 20Gbps port (1 x USB Type-C®) |
3 x USB 10Gbps ports (3 x Type-A) |
1 x USB 5Gbps port (1 x Type-A) |
2 x USB 2.0 ports (2 x Type-A) |
Front USB (Total 3 ports) |
1 x USB 20Gbps connector (supports USB |
Type-C®) |
1 x USB 5Gbps header supports 2 additional |
USB 5Gbps ports |
ROG STRIX HIVE II (Total 2 ports) |
2 x USB 10Gbps ports ( 1 x USB Type-C®+ 1 x |
Type-A) |
ROG FPS Card (Total 3 ports) |
2 x USB 2.0 headers support additional 3 |
USB 2.0 ports |
* USB Type-C® power delivery output: max. |
5V/3A |
Âm thanh | ROG Strix Hive II Audio Features |
- ROG Hyper-Grounding Technology |
- ESS® SABRE9260Q DAC |
- Silver-plated audio jacks |
- Dedicated audio PCB layers |
* All audio functions on ROG STRIX Z890-I |
GAMING WIFI are supported through the ROG STRIX HIVE II. |
Cổng I/O mặt sau | 2 x Thunderbolt™ 4 (2 x USB Type-C®) |
1 x USB 20Gbps port (1 x USB Type-C®) |
3 x USB 10Gbps ports (3 x Type-A) |
1 x USB 5Gbps port (1 x Type-A) |
2 x USB 2.0 ports (2 x Type-A) |
1 x HDMI™ port |
1 x Wi-Fi module |
1 x Intel® 2.5Gb Ethernet port |
1 x BIOS FlashBack™ button |
Đầu nối I/O nội bộ | Fan and Cooling Related |
1 x 4-pin CPU Fan header |
1 x 4-pin AIO Pump header |
1 x 4-pin Chassis Fan header |
1 x Extra Flow Fan header |
Power Related |
1 x 24-pin Main Power connector |
1 x 8-pin +12V CPU Power connector |
Storage Related |
2 x M.2 slots (Key M) |
USB |
1 x USB 20Gbps connector (supports USB |
Type-C®) |
1 x USB 5Gbps header supports 2 additional |
USB 5Gbps ports |
Miscellaneous |
2 x Addressable Gen 2 headers |
1 x 2-pin Power Button header |
1 x Thermal Sensor header |
2 x USB Type-C® connectors to install ROG |
FPS card |
ROG FPS card |
2 x SATA 6Gb/s ports |
1 x CPU Over Voltage jumper |
1 x Clear CMOS header |
1 x Front Panel header |
1 x Alteration PCIe Mode switch |
2 x USB 2.0 headers support 3 additional |
USB 2.0 ports |
BIOS | 256 Mb Flash ROM, UEFI AMI BIOS |
Hệ điều hành | Windows 11 (22H2 later) |
Form Factor | Mini-ITX Form Factor |
6.7 inch x 6.7 inch (17 cm x 17 cm) |
